• BV-13F

BV-13F

JIS 10K 2-PC BALL VALVE
FLANGED END TO JIS 10K DRILLED
FULL PORT.
BODY: FC20
SIZE: 1/2”~10”
(BV-13F) 2-PC BALL VALVE FLANGED END TO JIS 10K

(BV-13F) CAST IRON 2-PC BALL VALVE FLANGED END TO JIS 10K

* Please specify the required Model No. when ordering
* Face to Face Dimensions: JIS B2002 10K
* End Flanged Dimensions: JIS B2239
* Blow-Out proof Stem / Full Port
* Lever Operated or Gear Operated
* Gland type Pad
* PTFE +15%GF or +25%GF for Seat when required
* Test Pressure:  JIS B2003

Test Pressure:
Body:  2.1 Mpa / 21.5 kg/cm2(Hydrostatic)
Seat:  1.6 Mpa / 16.5 kg/cm2(By Water)
         0.6 Mpa / 6 kg/cm2(By Air)


          bv-13f.17f.23f.27f.34f.36f.44f.46f-5.png                              bv13f17f34f36f-3.png
